Product Details
TITAN FX
High mast lighting High reliable energy-efficient Lighting Solutions Wider range of Outdoor/Indoor Areas and Low cost, Excellent optics with impact-resistant tempered glass and anti-glare diffuser. it provides better and brighter illumination and also enables easier installation and maintenance of Lights due to motorized controls that lowers and raises the Lights
Brand: Fabae Lightings
Type : Outdoor Light/Indoor Light
Power : 70W, 100W, 150W, 200W, 300W, 400W, 500W, 800W, 1000W, 1500W
Application : Railway yards, Dockyards, Road Junctions, Toll Plazas, Warehouses, Stadium, Storage, Sport area lighting and Hanger Lighting
General Specification
Lamp : Integral LED, SMD
CCT : 3000K/4000K/6000K
CRI : >80
SDCM BINNING : <5
LED Life Time : >50,000h
LED Lm/W of Chip : 120-150 lm/W
Ambient Temperature : -20°C to 50°C
Storage Temperature : -30°C to 50°C
Humidity : RH 10% - 90%
IP Rating : IP65
Dimming : Possible
Body Color : Black
Tiltable : Yes
Mounting : Hook & Bracket Installation
Driver : Constant Current
Input Voltage : AC 100~240 V
Input frequency : 50/60 Hz
Power Factor : >0.9
THD : <15%
Housing Material : Aluminium die casting with cooling fins
Lens : -
Cover : Tempered glass diffuser
Prodcut Code & Specification
Product Code | POWER | LUMENS | BEAM ANGLE | DIMENSION (MM) |
---|---|---|---|---|
FB-TTFX.70 | 70W | 8400lm | 60° | D:390Ø, W:390xH:530 |
FB-TTFX.100 | 100W | 12000lm | 60° | D:390Ø, W:390xH:530 |
FB-TTFX.150 | 150W | 18000lm | 60° | D:390Ø, W:390xH:530 |
FB-TTFX.200 | 200W | 24000lm | 60° | D:390Ø, W:360xH:530 |
FB-TTFX.300 | 300W | 36000lm | 60° | D:390Ø, W:390xH:530 |
FB-TTFX.400 | 400W | 48000lm | 60° | D:390Ø, W:390xH:530 |
FB-TTFX.500 | 500W | 60000lm | 60° | D:390Ø, W:390xH:530 |
FB-TTFX.800 | 800W | 96000lm | 60° | D:445Ø, W:412,H:630 |
FB-TTFX.1000 | 1000W | 120000lm | 60° | D:460Ø, W:460,H:625 |
FB-TTFX.1500 | 1500W | 180000lm | 60° | D:445Ø, W:553,H:630 |
Downloads
